AA1165

Categories:
Tags:

About
Specifications

The AA1165 is a heavy-duty vertical machining center that features four Y-axis box guideways, a Meehanite cast iron base, and a high-performance spindle.

Additional Information

Table size	51.2" x 25.6" (1,300 mm x 650 mm)
X-axis Travel	43.3" (1,100 mm)
Y-axis Travel	25.6" (650 mm)
Z-axis Travel	23.6" (600 mm)
Max. Table Load	2,425 lb (1,100 kg)
Spindle Output Torque	CAT 50 Geared Head 6,000 RPM: 339 ft-lb (460 Nm)
Tool Storage Capacity	CAT40: 32 Standard (40 Optional)CAT50: 30 Standard (40 Optional)
Standard Floor Space	170" x 160" x 116" (4,308 mm x 4,068 mm x 2,940 mm)
Machine weight	15,873 lb (7,200 kg)
Chip Conveyor	Hinged Belt Lift Up type, 47" Drop Height from floor
